Sub-Category
LED T9 Circline
Bulb Dimmable
Non-Dimmable
Bulb Kelvin
3000K/4000K/6500K
EA Length
8.460000000000001
Harmonized Codes
8539.52.0010
Ship Carton Height
8.460000000000001
Warranty
5 Year Limited - 10 hr per day
Ballast Bypass Direct
Dual
Ballasting Requirements
Ballast required (Type A, Electronic only) or Ballast Bypass (Type B)
CEC
Exempt - Base Not Regulated
CEC Terse
Lawful for sale in California
CEC Web Text
Lawful for sale
Color Temprature
Soft White to Daylight
Efficacy
118.18/127.27/122.73 LPW
Enclosed Fixture Use
True
Feature 1
3 CCT Selectable
Feature 10
180 Degree Beam Angle
Feature 2
Range Voltage 120V-277V
Feature 3
Dual Mode Type A/B
Feature 4
Damp location rated
Feature 5
Rated for Enclosed Fixtures
Feature 6
50,000 Hour Functional Life
Feature 7
5 Year Warranty
Flourescent Equivalent
22W
Incandescent Equivalent
50W
Installation Notes
Not for use in vapor tight fixtures.
Lamp Ballast Type A/B/C
Type A/B
Long Description
SATCO|NUVO's S16510 LED 8-Inch Circline lamp is ideal for upgrading traditional fluorescent lighting to more energy efficient lighting in shallow, round ceiling and wall mounted fixtures. CCT selectable, choose from warm 3000K, neutral 4000K or choose
Material
Polycarbonate (PC)
Minimum Compartment Size
Length 11.4 in. Width 11.4 in. Height: 3.5 in.
Operating Frequency
50/60Hz
Operating Temp
-20C (-4F) to +45C (+113F)
Romance Copy
SATCO|NUVO's LED Circline lamps are ideal for upgrading traditional fluorescent lighting to more energy efficient lighting in shallow, round ceiling and wall mounted fixtures. CCT selectable, choose from warm 3000K, neutral 4000K or choose 6500K to bri
Short Description
FC8T9/LED/CIR/CCT/DM/A-B
Specification Notes
Only compatible with Electronic ballasts when installed in Type A mode. See ballast compatibility list for details. Not for use on magnetic ballasts.; Inner Diameter: 5.71 in.
Surge Protection
Built-in surge protection - 2.5KV
Total Harmonic Distortion
25%
